- Order number: 9300-02
- EAN: 4013456142510
- for halogen luminaires and pivoting LED luminaires
- max. installation height for low-voltage luminaire 65 mm, HV luminaire 70 mm
- Heat distortion resistant to 220°C
- lamp wattage LV: max. 35 W with AL reflector / 20 W Cool-Beam
- lamp wattage for HV luminaires max. 35 W with AL reflector (socket GU 10)
- max. LED lamp output 6.6 W
- Front can be used on both sides
Ceiling exit (CE) Ø
75 mm
Depth
90 mm
For panel thickness
7 – 40 mm
installation from front, cut hole Ø
120 mm
installation from rear, cut hole Ø
79 mm
Dispatch
10
Price/100 ST
2,660.00€
Price group
160
